2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble

Name: 2storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble
Brand: DEEPBLUE
Price: 1 USD

China 2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble wholesale

Brand Name : DEEPBLUE

Model Number : Touraine House

Certification : AS/NZS,UL,AISI,

Place of Origin : NINGBO,CHINA

MOQ : 1SET

Payment Terms : T/T,L/C,D/P,OA

Supply Ability : 12000houses/year

Delivery Time : 30-45days

Packaging Details : Bare bundle / 40HQ

Price : Negotiation

Material : Light Steel Frame

External Wall : 75mm ALC Panel

Internal Wall : CFC/Gypsum Board

Floor : MDF

Contact Now

2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble

Touraine House

4 bedrooms 5 bathrooms 3 living room 182.31 m²

This is a two-storey villa with an area of about 100 square meters. There is a terrace at the front and back, providing the owner with a place to relax. Open plan living room and kitchen, the room has a good private space. The living room sofa set is composed by a corner table, sofa and simple chair. Sofa section part allows 3 types of functions: arm rest, backrest and foot rest can freely be changed . In unique “madame la lune” style, it presents completely-air rested impact for comfortable seating experience.

2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble

The floor plan:

Applications:

House, Office, Villa, etc.

Description:

Main structure: Light Gauge Steel
Wall material: ALC panel/fiber cement cladding+MGO board/gypsum board
Insulation material: glass wool/EPS/XPS/PU sandwich panel
Ceiling material: MGO board/gypsum board
Floor/foundation material: laminate flooring/wooden/PVC carpet
Door: steel security door/WPC or plywood door
Window: aluminum alloy/PVC
Roofing: EPS sandwich panel/steel roofing/asphalt shingle
Other fittings: toilet, washbasin, shower, kitchen, etc.
Lifetime: 100 years for structure.

2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble
interior decoration chart:

Why Choose Light Gauge Steel Structure?

1) Lifetime for structure: 100 years.
2) Earthquake resistance: mix more than 8 grades.
3) Wind resistance: max 60m/s.
4) Fire resistance: all the materials used can be fire resistant.
5) Snow resistance: max 2.9KN/m²as required
6) Heat insulation: 100 mm in thickness can match 1 m thickness of the brick wall.
7) High acoustic insulation: 60db of exterior wall 40db of interior wall
8) Insect prevention: Free from the damages by insects, such as white ants
9) Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10) Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11) Installation: the average is one worker one day install one SQM.
12) Installation guide: dispatch engineer to guide on site.

2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble

Design Code:

1) AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
2) AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
3) BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
4) ENV1993-1-3 means Euro code 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.

2-storey House for Family Light Steel Fame Prefabricated Home Easy to Assemble

Our Services:

If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house
Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.
We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc.many style house.
